CAH (23) -400DT Two-shear and multi-punch servo cutting line series

CANWIN cross-cut line for separating cutting yoke and edge pieces

        The cross-cutting line is a special equipment for producing transformer cores and is the latest generation of our company's cross-cutting line. This production line is used to cut O punching holes and V notches of transformer core sheets. The special feature of the production line is that one O punch and two V notches can be used for the yoke of two-layer laminates; it can produce transformer core sheets with 3, 5, and 7 steps in the vertical direction and 3, 5, and 7 steps in the horizontal direction. After the silicon steel sheet coils are punched and cut into laminates of certain specifications, shapes and sizes by this production line, the grading and sorting work is completed at the end of the production line, and they are automatically stacked into 2 rows for use during core assembly. This production line adopts an advanced control system to ensure accurate and stable operation of the production line. The embedded operation terminal can complete parameter setting quickly and conveniently.

Features

1. The machine body is welded with high-quality steel, and the castings are punched and sheared. The mounting surface is made of thickened steel plate. The structure is strong and firm, and heat treatment eliminates the risk of deformation.

2. The punching and shearing machine mainly uses high-quality castings, which never deform, which helps ensure shearing accuracy and increase the service life of the tool; at the same time, it effectively eliminates the chatter and noise of impact shearing.

3. The optimized feeding and feeding system has stable and reliable performance, ensuring that silicon steel sheets can be transported at high speed.

4. The punching and shearing mechanism is driven by a high-response servo motor, which is precise and efficient.

5. The punching and shearing parts are made of high-quality carbide, which has long service life and low wear.

6. Adopt Siemens electronic control system to achieve precise measurement of length shear, full closed-loop control, online detection and automatic fine-tuning.

7. The width adjustment device is driven by a servo motor and controlled by a computer to realize automatic width adjustment.
